Products Description
Expanded PTFE gasket sheet is made of 100% expanded P.T.F.E. by using special process that produces a uniform and highly fibrillated microstructure with a great lot of fibers running in multidirection. These create a soft and pliable, yet very tough gasket that has excellent resistance of pressing, creep relaxation and cold flow.
Expanded PTFE sheet possesses universal resistance against common chemicals, except melted alkali metal, fluorine at liquid and gas states. It can be stored without any time limits and can seal uneven and damaged flanges
- full chemical resistance like solid sintered PTFE
- resistance against acids and bases of pH 0 to 14
- UV-resistant
- no aging, unlimited shelf life
- nontoxic, biologically inert
- non flammable
Specification of expanded ptfe sheets
Model | Thickness (mm) | Size (mm) |
WXXJ-05-E | 0.5 | 1500X1500; 1800X1800 |
WXXJ-10-E | 1.0 | |
WXXJ-15-E | 1.5 | |
WXXJ-20-E | 2.0 | |
WXXJ-30-E | 3.0 | |
WXXJ-40-E | 4.0 | |
WXXJ-50-E | 5.0 | |
WXXJ-60-E | 6.0 | |
WXXJ-70-E | 7.0 | |
WXXJ-80-E | 8.0 | |
WXXJ-90-E | 9.0 | |
WXXJ-100-E | 10.0 | |
we can develop customized product to meet your specific needs. | ||
Physical Properties of expanded ptfe sheets
Length Tensile Strength | 17.0MPa |
Cross Tensile Strength | 17.0MPa |
Compressive Strength | 17.0MPa |
Max Compressive Strength | 17.0MPa |
Gravity | 0.65~0.95g/cm³ |
Compression | WXXJ 45% JB/T10688-2006 40%~50% |
Recovery | WXXJ 15% JB/T10688-2006 >10% |
Leakiness (cm³/s) | WXXJ 0.1~0.2x10-4 JB/T10688-2006 <0.1x10-3 |
Temperature | -240~260°C |
